CAB MACH4 User Manual

16 16
4 Loading Material
4.5 Loading Transfer Ribbon
i
Notice!
Do not insert a transfer ribbon for direct thermal printing.
!
Attention!
When inserting the transfer ribbon ensure that the coated side faces the labels, as otherwise the printhead
can become soiled.
4 521 3 2
726 8 9 7 10 11 8
Fig. 9 Loading Transfer Ribbon

CAB MACH4 Specifications

General

Print Technology	Thermal transfer
Print Resolution	300 dpi
Max Print Width	104 mm
Power Supply	100 - 240 V AC, 50/60 Hz
Display	LCD with backlight
Interfaces	USB, Ethernet
Label Width Range	25 mm - 116 mm
Supported Barcode Types	Data Matrix, QR Code
Supported Operating Systems	Windows, Linux
