Fig. 33 - Remove screws Fig. 34 - Fold aps
Fig. 35 - Insert side panels Fig. 36 - Position cover
5.6 MOUNTING THE VERVE AIRTIGHT SIDE PANELS
• Remove the front panel: loosen the 4 screws (see Fig. 37).
• Hook the coloured panels: fit the front part between the guides on the stove, then hook back through the teeth (see Fig. 38).
• Position the front panel (see Fig. 39).
