8.2 FEATURES
DESCRIPTION KRISS
3
- 7 kW EVO
3
- 7 kW CRISTAL
3
- 8,5 kW
WIDTH 52,8 cm 51,5 cm 45,5 cm
DEPTH 52,8 cm 48,5 cm 51 cm
HEIGHT 94,1 cm 94,5 cm 97 cm
WEIGHT 88 kg 81 - 90,5 - 126 kg 79 kg
INTRODUCED THERMIC POWER (Min/Max) 2,58 - 7,96 kW 2,58 - 7,96 kW 2,58 - 9,73 kW
NOMINAL THERMIC POWER (Min/Max) 2,4 - 7,15 kW 2,4 - 7,15 kW 2,4 - 8,67 kW
EFICIENCY (Min/Max) 92,91 - 89,8 % 92,91 - 89,8 % 92,91 - 89,14 %
FUME TEMPERATURE (Min/Max) 95,3 - 171,5 °C 95,3 - 171,5 °C 95,3 - 196,6 °C
FUME MAXIMUM LOADING CAPACITY (Min/Max) 2,2 - 4,4 g/s 2,2 - 4,4 g/s 2,2 - 4,8 g/s
CO EMISSIONS (13% O
2
) (Min/Max) 0,022 - 0,004 % 0,022 - 0,004 % 0,022 - 0,006 %
OGC EMISSIONS (13% O
2
) (Min/Max) 3,9 - 0,3 mg/Nm
3
3,9 - 0,3 mg/Nm
3
3,9 - 1,5 mg/Nm
3
NO
X
EMISSIONS (13% O
2
) (Min/Max) 104,4 -134,4 mg/Nm
3
104,4 -134,4 mg/Nm
3
104,4 -135,7 mg/Nm
3
Medium CO CONTENTS at 13% O
2
(Min/Max) 274 - 44 mg/Nm
3
274 - 44 mg/Nm
3
274 - 79 mg/Nm
3
Medium POWDER CONTENTS at 13% O
2
(Min/Max) 19,3 - 13,4 mg/Nm
3
19,3 - 13,4 mg/Nm
3
19,3 - 14 mg/Nm
3
CHIMNEY DEPRESSION (Min/Max) 7,7 - 11,5 Pa 7,7 - 11,5 Pa 7,7 - 11,6 Pa
ON SHARED CHIMNEY FLUE NO NO NO
FUME OUTLET DIAMETER Ø80 mm Ø80 mm Ø80 mm
COMBUSTIBLE Pellet Ø6-7 mm Pellet Ø6-7 mm Pellet Ø6-7 mm
PELLETS HEATING VALUE 5 kWh/kg 5 kWh/kg 5 kWh/kg
PELLETS HUMIDITY ≤ 10% ≤ 10% ≤ 10%
HEATING VOL. 18/20°C Coeff. 0,045 kW (Min/Max) 58 - 172 m
3
58 - 172 m
3
58 - 208 m
3
HOURLY CONSUMPTION (Min/Max) 0,53 - 1,65 kg/h 0,53 - 1,65 kg/h 0,53 - 2,01 kg/h
HOPPER CAPACITY 18 kg 18 kg 18 kg
RANGE (Min/Max) 34 - 10,9 h 34 - 10,9 h 34 - 9 h
SUPPLY 230 V - 50 Hz 230 V - 50 Hz 230 V - 50 Hz
POWER INPUT (Max) 364 W 364 W 346 kW
INGNITER RESISTANCE POWER INPUT 300 W 300 W 300 W
MINIMUM EXTERNAL AIR INLET (last effective area) 80 cm
2
80 cm
2
80 cm
2
STOVE WITH SEALED CHAMBER YES YES YES
EXTERNAL AIR INLET FOR SEALED CHAMBER 60 mm 60 mm 60 mm
DISTANCE FROM COMBUSTIBLE MATERIAL
(back/side/bottom)
200 / 200 / 0 mm 200 / 200 / 0 mm 200 / 200 / 0 mm
DISTANCE FROM COMBUSTIBLE MATERIAL
(ceiling/front)
0 / 1000 mm 0 / 1000 mm 0 / 1000 mm
