Cadel KRISS3 - Mounting the Glass Door

KRISS
3
- TECNA
3
- EVO
3
- ELISE
3
- SHELL
3
- CRISTAL
3
- GLASS - VERVE AT - PRETTY AT - TITANIA AT - VENERE AT - BREEZE AT
24
Fig. 37 - Remove the front panel Fig. 38 - Hook the panels Fig. 39 - Position the front panel
5.7 MOUNTING THE GLASS DOOR
• Tighten the screws on the bushes on the glass: 4 screws with round heads and 2 screws with flat heads (see Fig. 40).
• Position the glass on the metal door: hook the screws' heads on the door's holes (see Fig. 41).
• Lock the screws (see Fig. 42).
• If required, adjust the door from the relative screws on the hinges (see Fig. 43).
Fig. 40 - Tighten the screws Fig. 41 - Position the glass
Fig. 42 - Locking the screws Fig. 43 - Door adjustment
