30
Fig. 69 - Loosen screws Fig. 70 - Remove side panels
5.15 BREEZE AIRTIGHT SIDE PANEL DISASSEMBLY
To access the internal stove parts, disassemble the side panels as indicated below:
• Remove the cast iron cover (see Fig. 71).
• Loosen the rear screws of the sides (see Fig. 72).
• Open the side and release it from the teeth (see Fig. 73).
• To assemble proceed in reverse order.
Fig. 71 - Top removal Fig. 72 - Remove screws Fig. 73 - Removing the side panel
5.16 ELECTRIC CONNECTION
Warning: the appliance must be installed by an authorized technician!
• The electric connection occurs through a cable with plug put in an electric socket which is able to support charge and tension
specific of every model, as described in the technical datas table (see FEATURES a pag. 40).
• The plug must be easily accessible when the appliance is installed.
