Cadel KRISS3 - Overall Dimensions

13
KRISS
3
- TECNA
3
- EVO
3
- ELISE
3
- SHELL
3
- CRISTAL
3
- GLASS - VERVE AT - PRETTY AT - TITANIA AT - VENERE AT - BREEZE AT
5.2 OVERALL DIMENSIONS
Fig. 17 - General dimensions: Tecna
3
LEGEND Fig. 17
1 49,1 cm
2 96,1 cm
3 48,8 cm
4 23,8 cm
5 32,5 cm
6 16 cm
7 Exhaust fumes d.8 cm
8 Hole combustion air inlet d.6 cm
9 20 cm
Fig. 18 - General dimensions: Evo
3
