SW1 +6dBu at the scale "0" position (PPM only):-
1 = LEFT BAR } UP = ON = +6dBu at scale "0".
2 = RIGHT BAR } DOWN = OFF = +8dBu at scale "0".
SW2 PPM/VU characteristics, LEFT BAR :-
LEFT = PPM
RIGHT = VU
SW3 PPM/VU characteristics, LEFT BAR :-
LEFT = VU
RIGHT = PPM
SW4 PPM/VU characteristics (Not available on MU4710):-
1 = LEFT BAR } UP = ON = VU
2 = RIGHT BAR } DOWN = OFF = PPM
SW5 PPM/VU characteristics, RIGHT BAR(Not available on MU4710) :-
LEFT = VU
RIGHT = PPM
SW6 PPM/VU characteristics, RIGHT BAR (Not available on MU4710):-
LEFT = VU
RIGHT = PPM
The Standard Default settings for all bargraphs will follow other metering or be set for VU.
