Calrec M3 - INPUTS - XLR’s

M3
...................................................................................................................................................................................
36
INPUTS - XLR’s
XLR 3 Connector Pin Information (fixed sockets on console)
Pin 2 - Hot, or Phase
Pin 3 - Cold, or Anti-phase
Pin 1 - Chassis or Earth
Channel Inputs
Module Type fitted XLR Ref Circuit for channel slots 1-10 (Small chassis), slots
1-24 (Medium chassis) or slots 1-38 (Large chassis -
unless group modules fitted).
PQ5122 1 MIC Input
(Mono dual Input) 2 2nd Input either MIC or LINE
or
PQ5123 1 MIC Input L
(Stereo Mic) 2 MIC Input R
or
BQ5124 1 LINE Input L
(Stereo Line) 2 LINE Input R
Group Inputs
Module Type fitted XLR Ref Circuit for channel/group slots 7-10 (small chassis),
slots 21-24 (Medium chassis) or slots 35-38 (Large
chassis
XL5125 1 Direct Input - M
(Mono) 2 not used
or
XL5126 1 Direct Input - L
(Stereo) 2 Direct Input - R
Main Input 1
Module Type fitted XLR Ref Circuit for Main module in Main 1 slot
LC5127 1 Direct Input - L
(Main 1) 2 Direct Input - R
Main Input 2
Module Type fitted XLR Ref Circuit for Main module in Main 2 slot
LC5128 1 Direct Input - L
(Main 2) 2 Direct Input - R
or
TB3808 1 not used
(Talkback) 2 not used
Monitor
No Inputs are available XLR Connectors
