Calrec M3 - OUTPUTS - XLR’s

M3
...............................................................................................................................................................................
37
OUTPUTS - XLR’s
XLR 3 Connector Pin Information (fixed plugs on console)
Pin 2 - Hot, or Phase
Pin 3 - Cold, or Anti-phase
Pin 1 - Chassis or Earth
Main Output 1
Module Type fitted XLR Ref Circuit for Main module in Main 1 slot
LC5127 L LINE Output 1L
(Main 1) R LINE Output 1R
M LINE Output 1M
AUX 1 AUX Output 1M
AUX 2 AUX Output 2M
AUX 3 AUX Output 3M
AUX 4L AUX Output 4L
AUX 4R AUX Output 4R
Main Output 2
Module Type fitted XLR Ref Circuit for Main module in Main 2 slot
LC5128 L LINE Output 2L
(Main 2) R LINE Output 2R
M LINE Output 2M
Monitor 1
Module Type fitted XLR Ref Circuit for Monitor module in Monitor 1 slot
ML4952
Mon LS L Monitor Loudspeaker Output L
(Monitor 1) Mon LS R Monitor Loudspeaker Output R
Monitor 2
Module Type fitted XLR Ref Circuit for Monitor module in Monitor 2 slot
ML4953 PFL LS PFL Loudspeaker Output M
No other outputs are available on XLR connectors.
