M3
...............................................................................................................................................................................
13
MOUNTING THE M3
The M3 console has been designed to allow for maximum flexibility of use, in that it can be placed
into a site for temporary operation, or fixed into a permanent location.
All console chassis sizes have been designed to allow for mounting in several different ways, as
follows:
• Directly on top of a table top or small equipment rack/trolley.
• Vertically into equipment racking, when chassis is fitted with side support angles* .
• Horizontally into equipment racking, when chassis is fitted with side support angles* .
• Alternatively, the chassis can be ‘dropped through’ the control surface for a permanent
location. The console can either be supported along its lower edge, or from a pair of side
support angles*.
• On a factory supplied stand (Large Chassis only).
* Small and Medium chassis sizes only.
NB. During both Installation & operation, care must be taken to ensure that the ventilation holes
are not blocked & that adequate ventilation is supplied to these areas.
