Calrec M3 - Page 81

M3
...............................................................................................................................................................................
81
Each channel has the option of sending to a Direct Output or to the Mix Minus Bus (via a switch
on the front panel). Both options can be set internally to be either pre or post fader.
Direct Output - Post fader SW 44 1 - ON
2 - OFF
Direct Output - Pre fader SW 44 1 - OFF
2 - ON
Mix Minus - Post fader SW 44 3 - ON
4 - OFF
Mix Minus - Pre fader SW 44 3 - OFF
4 - ON
Channel Insert Go can be taken either Pre or Post fader, or bypassed altogether if not required
for use. The signal is always present at the Insert Go connector in all conditions.
Insert - Pre fader SW 39 1 - ON
2 - OFF
SW 35 1 - OFF
2 - ON
SW 31 1 - ON
2 - OFF
Insert - Post fader SW 39 1 - OFF
2 - ON
SW 35 1 - ON
2 - OFF
SW 31 1 - OFF
2 - ON
Insert - Bypassed SW 35 1 - ON
2 - OFF
SW 31 1 - ON
2 - OFF
When Aux 1 PA Inhibit is enabled, it allows a signal only to be fed to the audience PA system
only whilst either the channel fader is open or under external VCA control. It works regardless
of whether the signal is being taken pre or post fader.
Aux 1 PA Inhibit enabled SW 8 1 - OFF
to follow fader 2 - ON
Aux 1 PA Inhibit enabled SW 8 1 - ON
to follow ext. VCA control 2 - OFF
Aux 1 PA Inhibit not SW 8 1 - OFF
selected 2 - OFF
Standard default settings
Standard default settings
Standard default settings
Standard default settings
