Calrec M3 - Page 85

M3
...............................................................................................................................................................................
85
Each channel has the option of sending to a Direct Output or to the Mix Minus Bus (via a
switch on the front panel). Both options can be set internally to be either pre or post fader.
Direct Output - Post fader SW 37 1 - ON
2 - OFF
3 - ON
4 - OFF
Direct Output - Pre fader SW 37 1 - OFF
2 - ON
3 - OFF
4 - ON
Mix Minus - Post fader SW 18 1 - ON
2 - OFF
Mix Minus - Pre fader SW 18 1 - OFF
2 - ON
When Aux 1 PA Inhibit is enabled, it allows a signal only to be fed to the audience PA
system only whilst either the channel fader is open or under external VCA control. It
works regardless of whether the signal is being taken pre or post fader.
Aux 1 PA Inhibit enabled SW 8 1 - OFF
to follow fader 2 - ON
Aux 1 PA Inhibit enabled SW 8 1 - ON
to follow ext. VCA control 2 - OFF
Aux 1 PA Inhibit not SW 8 1 - OFF
selected 2 - OFF
Standard default settings
Standard default settings
Standard default settings
