Calrec M3 - Page 87

M3
...............................................................................................................................................................................
87
Mono Groups have the option of being fed with either a mono mix signal or a Left /Right
split to pairs of group mono modules. Left signal going to positions 1 & 3, Right to 2 & 4.
L/R Input Mix ON SW 2 1 - ON
2 - ON
L/R split to gps 1&3 / 2&4 SW 2 1 - OFF
2 - OFF
When Aux 1 PA Inhibit is enabled, it allows a signal only to be fed to the audience PA
system only whilst the fader is open.
Aux 1 PA Inhibit enabled SW 7 1 - ON
to follow fader 2 - OFF
Aux 1 PA Inhibit not SW 7 1 - OFF
selected 2 - ON
Each group has the option of sending to a Direct Output. The signal can be set internally
to be either pre or post fader.
Direct Output - Post fader SW 13 1 - ON
2 - OFF
Direct Output - Pre fader SW 13 1 - OFF
2 - ON
Standard default settings
Standard default settings
Standard default settings
