Calrec M3 - Page 89

M3
...............................................................................................................................................................................
89
When Aux 1 PA Inhibit is enabled, it allows a signal only to be fed to the audience PA
system only whilst the fader is open.
Aux 1 PA Inhibit enabled SW 7 1 - ON
to follow fader 2 - OFF
Aux 1 PA Inhibit not SW 7 1 - OFF
selected 2 - ON
Each group has the option of sending to a Direct Output. The signal can be set internally
to be either pre or post fader.
Direct Output - Post fader SW 12 1 - ON
2 - OFF
3 - ON
4 - OFF
Direct Output - Pre fader SW 12 1 - OFF
2 - ON
3 - OFF
4 - ON
Standard default settings
Standard default settings
