The bargraph characteristics can be set to display as either PPM or VU.
PPM SW 5 1 - OFF
2 - ON
VU SW 5 1 - ON
2 - OFF
On the bargraph display the bar at the ‘0’ position can be set to brighten, when the signal is
either 0dBu, +4dBu, +6dBu or +8dBu.
0dBu SW 6 1 - ON
2 - ON
+4dBu SW 6 1 - ON
2 - OFF
+6dBu SW 6 1 - OFF
2 - ON
+8dBu SW 6 1 - OFF
2 - OFF
The headphone output is set to follow the monitor LS outputs. However it can be selected
to be taken either pre or post the LB, RB, Mono & Phase Reverse switching.
Headphone O/P - Pre SW 4 1 - OFF
2 - ON
3 - OFF
4 - ON
Headphone O/P - Post SW 4 1 - ON
2 - OFF
3 - ON
4 - OFF
The headphone output can be as normal, (no phase reverse) or can have a phase reverse
on the Right Signal.
NML SW 26 1 - ON
2 - OFF
Phase Reverse on Right SW 26 1 - OFF
2 - ON
Standard default settings
Standard default settings
Standard default settings
Standard default settings
