The bargraph characteristics can be set to display as either PPM or VU.
PPM SW 18 1 - OFF
2 - ON
VU SW 18 1 - ON
2 - OFF
On the bargraph display the bar at the ‘0’ position can be set to brighten, when the signal is
either 0dBu, +4dBu, +6dBu or +8dBu.
0dBu SW 6 1 - ON
2 - ON
+4dBu SW 6 1 - ON
2 - OFF
+6dBu SW 6 1 - OFF
2 - ON
+8dBu SW 6 1 - OFF
2 - OFF
The talkback enable switching can be set to be ON permanently, regardless of transmission
status, or ON only when the desk is in Rehearsal mode, or permanently OFF
ON SW 2 1 - ON
2 - OFF
ON in Rehearsal mode SW 2 1 - OFF
2 - ON
OFF SW 2 1 - OFF
2 - OFF
The small internal PFL loudspeaker can be either ON, or MUTED if the output is to be fed
to an external PFL LS
ON SW 1 1 - ON
2 - OFF
MUTED SW 1 1 - OFF
2 - ON
Standard default settings
Standard default settings
Standard default settings
Standard default settings
