Appendix C - Head Types
The Calsense CS3000 controller has 13 head type or sprinkler type selections to choose from for each
zone. The head type selection will affect the precipitation rate. Caution: The information and
measurements provided below are generalized and may vary depending on adjustments made.
Head Type Description Pressure/Precipitation Rate Range
Spray
Applies a constant 360-degree fan of
water over given area.
Operating pressure around 30 psi, and
precipitation rate of 1.5 - 2.0
inches/hour.
360 degrees
Radius of 2-20 feet
Spray-Stream
Applies a constant 360-degree fan of
water over given area.
Operating pressure around 30 psi, and
precipitation rate between 1.5 - 2.0
inches/hour.
360 degrees
Radius of 2-20 feet
Spray-High Efficiency
Applies a constant 360-degree fan of
water over a given area. Produces larger
water droplets at a slower rate, reducing
carry away from wind.
Operating pressure around 45 psi, and
precipitation rates between 0.4 - 0.8
inches/hour.
360 degrees
Radius of 2-20 feet
Rotor-Full Circle
Single stream of water rotating 360
degrees.
Operating pressure between 40-110
psi, and precipitation rates between
0.25 - 1.5 inches/hour.
360 degrees
Radius of 15-100 feet
Rotor-Part Circle
Single stream of water rotating back and
forth at adjustable angles less than 360
degrees.
Operating pressure between 40-110
psi, and precipitation rates of 0.25 -
1.5 inches/hour.
Adjustable angles < 360
degrees
Radius of 15-100 feet
Rotor-Mixed
Single stream of water that rotates back
and forth. Adjustments between 40 and
360 degrees.
Operating pressure between 40-110
psi, and precipitation rates of 0.25 -
1.5 inches/hour.
Adjustable angles < 360
degrees
Radius of 25-100 feet
Rotor-Stream
Single stream of water that rotates back
and forth within adjusted parameters.
Operating pressure between 40-110
psi, and precipitation rates of 0.25 -
1.5 inches/hour.
360 degrees
Radius of 25-100 feet
Impact-Full Circle
Ideal for large open areas. Proving even
radius 360 degrees. The force of the
outgoing water drives the head in a
circular motion.
Operating pressure between 25-50 psi,
and precipitation rates of 0.3 - 0.9
inches/hour.
360 degrees
Radius up to 50 feet
Impact-Part Circle
Ideal for large open areas. Stream of
water with adjustable rotation less than
360 degrees. Force of the outgoing water
drives the head in a circular motion.
Operating pressure between 25-50 psi,
and precipitation rates of 0.3 - 0.9
inches/hour.
Adjustable angles < 360
degrees
Radius up to 50 feet
