Appendix A – Troubleshooting Alerts
Problem
Description
Possible Causes
Solution
2-Wire Cable Excessive
Electrical Current
2-wire cable exceeded the
electrical threshold
Blue and red wires are
improperly installed
Correct wire installation
Nicked wire
Check wiring and replace or fix
wires
Shorted 2-wire path or decoder Correct wire installation
Failed solenoid Replace solenoid
2-Wire Terminal Overheated
2-wire terminal overheated due
to excessive heat
Temperature exceeded
maximum threshold
Call Calsense customer service or
your Account Manager
Electrical short:
Pump
An electrical short was detected
on pump output.
Wires are not properly
installed
Correct wire installation
Bad coil Replace coil
Wires are crossed Adjust wire placement
Wire splices are not watertight
Locate wire splices and adjust
according
Electrical short:
Lights Output <num>
An electrical short was detected
on lights output.
Wires are not properly
installed
Correct wire installation
Wires are crossed or
disconnected
Adjust wire placement
Wire splices are not watertight
Locate wire splices and adjust
according
Electrical Short:
Unknown Output
An electrical short was detected
from an unknown output.
Power surge
Wires are crossed Adjust wire placement
Wire splices are not watertight
Locate wire splices and adjust
according
Damaged wires
Check wiring and replace or fix
wires
No Electrical Current:
Master Value
No electrical current was
measured from master valve.
Broken Wire
Locate and fix the wire connection
Burnt out solenoid
Replace solenoid
Disconnected wires
Locate and fix the wire connection
No Electrical Current:
Lights Output <num>
No electrical current was
measured from lights output.
Wires are not properly
installed
Locate and fix the wire connection
No Electrical Current:
Station <num>
No electrical current was
measured on an indicated
station.
Wires are not properly
installed
Locate and fix the wire connection
ET Gage- 0 Pulses
Zero pulses are being measured
from ET gage.
Weather conditions Adjust for weather conditions
No power connected Check power to gage
ET gage is out of water Check water level
FLOWSENSE®
Communication Down-
Irrigation will not run
FLOWSENSE is unable to
connect
Communication cable is not
properly installed
Check wiring
Incorrect control setting Adjust control settings
Improper radio coverage
Conduct radio survey to confirm
proper radio coverage
