CAME FROG series Installation Instructions

26
5.7 - Control Panel Adjustments
Fig 27
Trimmer T.L. - Adjustment of operating time from a minimum of 0 seconds to a
maximum of 120 seconds N.B. it is advised to let the motors run on for between 6 and 8
seconds after the last gate has fully close.
Trimmer T.C.A - Adjustment of automatic closing time from a minimum of 1 to a
maximum of 120 seconds.
T.L T.C.A
TRIMMERS
ADJUSTMENT

CAME FROG series Specifications

General

Motor Voltage	24 V DC
Max Gate Weight	800 kg
Duty Cycle	30%
Limit Switch	Yes
Power Supply	230 V AC
Safety Features	Obstacle detection
Type	Electromechanical underground gate opener
