4. TROUBLESHOOTING GUIDE
A MULTIMETER WILL BE NEEDED
PROBLEM SOLUTION
GATE WILL NOT RESPOND
WHEN GIVEN A COMMAND
1. CHECK POWER SUPPLY TO THE
CONTROL PANEL.
2. CHECK CONTROL PANEL FUSES.
3. CHECK HARD WIRE LINK FITTED
BETWEEN TERMINALS 1 & 2.
4. CHECK THAT CAPACITORS ARE
FITTED AND WIRED CORRECTLY.
1. CHECK SAFETY BEAMS ARE WIRED
CORRECTLY. (IF MORE THAN ONE
SET OF BEAMS ARE FITTED THEY
MUST BE WIRED IN SERIES.)
2. CHECK THAT THERE IS POWER
GOING TO THE BEAMS, IF NOT
RESTORE POWER.
3. IF SAFETY BEAMS ARE NOT FITTED
ENSURE THAT A HARD WIRE IS
FITTED BETWEEN TERMINALS 2 &
C1.
4. REMOVE SAFETY BEAM WIRES 2 &
C1 FROM CONTROL PANEL AND
CHECK IF YOU HAVE A NORMALLY
CLOSED CIRCUIT COMING FROM
THE BEAMS.
1. MOTOR WIRES ARE WRONG WAY
ROUND. CHECK AND PROVE MOTOR
DIRECTION BY MOMENTORIALLY
PULSING TERMINALS 2 & 3. THE
GATE SHOULD OPEN UP. TURN
AUTOMATIC CLOSING
OFF
(DIP
SWITCH 2) UNTIL MOTOR
DIRECTION HAS BEEN PROVED.
WHEN COMMISSIONING
GATE AUTOMATICALLY OPEN
BUT DO NOT
AUTOMATICALLY CLOSE
GATE IS OPEN BUT WILL
NOT CLOSE AND GREEN LED
IS FLASHING
19
CONTINUED ON NEXT PAGE
