CAME ZM3E User Manual

p. 20 - Manual FA01317-EN - 01/2020 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Lock
Associate the electric lock release with a command.
[FUNCTIONS] [Lock] [Deactivated] (Default)
[Close]
[Open]
[Open-Close]
Confi gurations
Confi gure slowdowns and limit switches.
[Slow.] and [Op.LS-Cl.Slow.] must be confi gured with the [Slow. T.].
[FUNCTIONS] [Confi g] [Slow.] = Slowdown during opening and closing
[Op.LS-Cl.Slow.] = Opening limit-switch and closing
slowdown.
[ENCODER] = Encoder (Default)
[Time LS] = Time limit switch
[Limit switch] = Opening and closing limit-switches
Limit switch
Confi gure the limit switch contacts as NO or NC.
This function only appears when one of the follow parameters is selected from the [Confi g] function: [Limit
switch] [Op.LS-Cl.Slow.] [Slow.].
[FUNCTIONS] [Limit switch] [N.C.] (Default)
[N.O.]
Command 2-7
Associate a command with the device connected to 2-7.
[FUNCTIONS] [Command 2-7] [Open-Close](Default)
[Op. Stop Cl.]
Command 2-3P
Associate a command to the connected device on 2-3P.
[FUNCTIONS] [Command 2-3P] [Partial]
The degree of opening of the leaf is set with the
[Part. open] function in the [SET TIME] menu.
[Pedestrian] (Default)
Additional light
Choose the operating mode of the lighting device connected to the output.
[FUNCTIONS] [Light E] [Courtesy]
The light stays on for 5 minutes.
[Cycle] (Default)
The lamp stays on during the manoeuvre.
The light remains o if an automatic closing time
is not set.

CAME ZM3E Specifications

General

Protection Rating	IP54
Operating Temperature	-20°C to +55°C
Manufacturer	CAME
Model	ZM3E
Type	Control Panel
Power Supply	230V AC
