CANNON® Operating the CAV 4.2
VISCPRO® II software interface
VISCPRO® II is a Windows® software program comprising the general interface application
and instrument/analysis-specific modules. Figure 29 shows a typical VISCPRO II interface with
an open instrument window, analysis log, application specific status window, and general
information status windows.
Table 20 — VISCPRO window details
Area
Detail
Click to open a window for …
VISCPRO II Menu
Main
… managing the VISCPRO application.
Analyses
… displaying, configuring, and managing
analysis logs.
Configure
… configuring the settings of attached
instruments.
Service
… servicing an attached instrument.
Window
… managing the open windows.
Help
… managing VISCPRO help.
CAV 4.2 Instrument
Window
Use this window to view the status of the instrument and
manage sample test runs.
Analysis Log
Displays a specific analysis report.
Information Status Bar
General
Click to open the general information
status window.
VI Matching
Click to open the VI Matching information
status window.
<instrument>
Click to open a status window for a
particular instrument.
