CANNON®
CAV® 4.2 Operator's Manual, Rev. 2.0
Specifications
Table 29 — Specifications
Specifications
Details
Model
CAV® 4.2
Methodology
ASTM D445, ISO 3104, IP 71, ASTM D446, ISO 3105
Applications
Formulated oil analysis, hydraulic oil analysis, additive
analysis, marine fuel testing, base stock analysis, light and
heavy fuel testing, waxes/paraffin, crude oil testing, glycols
Dimensions (W × D × H)
36 cm × 66 cm × 72 cm (14.25 in × 26 in × 28.5 in)
Weight
63 kg (140 lb)
Operational temperature
range
20 °C to +100 °C (± 0.01 °C); without a TE bath cooler, the
minimum temperature is +5 °C above ambient temperature
Up to 150 °C (± 0.03 °C) with integrated high temperature
bath
Down to 15 °C (± 0.03 °C) with integrated TE bath cooler
Maximum throughput
24 tests per hour
Automated sample capacity
28 positions (2 × 14 positions)
Minimum sample/solvent
volume required
8 mL sample/15 mL solvent per test
Viscosity range
0.5 mm²/s to 10,000 mm
2
/s in 100-fold increments
(depending on viscometer tubes selected). Fast run tubes
are also available.
Timing resolution
0.01 seconds (timing accuracy to ± 0.001 seconds)
Power requirements
100 V
AC
, 50/60 Hz, 1200 Watts
115 VAC, 50/60 Hz, 1200 Watts
230 V
AC
, 50/60 Hz, 1200 Watts
