Canon imagePROGRAF iPF710 User Manual

Printing from Windows
Printing
Print from the application software menu.
1
In the application software, select Print from the File menu to display the dialog
box for printing conditions.
2
After confirming that the printer is selected in the dialog box, click Print or OK to
start printing.
Note
•
The appearance of the dialog box varies depending on the application softw are. In
most cases, the dialog b ox in c lud es basic printing options and enab les you to choose
the printer, s pecify the range of pages, number of cop ies, and so on .
Example: Print dialog box displayed by the application software
•
If another p rinter is selected, sel ect the printer you want to use under Select Printer
or in the dialog box displayed after clicking Printer.
22

Canon imagePROGRAF iPF710 Specifications

Printer Specifications

print resolution (max.)	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm
number of nozzles	Matte Black: 5, 120 Nozzles, Other Colors: 2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print head swath	1.07 inch

Ink Specifications

ink type	Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K); Pigment: Matte Black (MBK) – Two Channels
ink tank capacity	130ml per Color
number of colors	5

Media Specifications

media width (roll feed)	10" – 36" (254mm – 914.4mm)
media width (cut sheet)	8" – 36" (203.2mm – 914.4mm)
printable margins (roll feed)	All Sides: 0.12" (3mm) or 0" for Borderless
minimum printable media length (roll feed)	8.0" (203mm)
maximum print length (roll feed)	59' (18m)
maximum print length (cut sheet)	5.2' (1.6m)
borderless printing widths (roll media only)	10", 14", 16", 24", 36", B2 (20.28"/515mm), A1 (23.38"/594mm), B1 (28.66"/728mm), AO (33.11"/841mm)
media thickness (roll feed)	0.07 – 0.8mm (2.8 – 31.4mil)
media thickness (cut sheet)	0.07 – 0.8mm (2.8 – 31.4mil)
media core sizes	2" or 3" Core (2/3" Core Adapter Included)
maximum roll outer diameter	5.9" (150mm)

Power and Acoustic

power supply	AC 100–240V (50-60Hz)
power consumption (maximum)	140W or Less
power consumption (standby)	5W or Less (10W or less when IEEE1394 is mounted)
power consumption (power off)	1W or Less (Executive Order Compliant)
acoustic noise (operation)	52dB (A) or Less
acoustic noise (standby)	35dB (A) or Less
acoustic power	6.6 Bels or Less

Operating Environment

operational temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (h x w x d)	59.3" x 34.3" x 43.1" / 1507mm x 871mm x 1094mm
weight (with stand)	Approx. 141 lb. / 64kg
