Canon imagePROGRAF iPF710 User Manual

60
Troubleshooting If You Cannot Print
Printing Does Not Start
The Data lamp on
the Control Panel
does not light up
The printer is not on. Make sure the power cord is securely plugged in, all the
way. Press the Power button to turn the printer on.
In Mac OS X, select the printer by clicking Printer
Setup Utility (or Print Center ) and try printing again.
In Mac OS 9, select the printer in Chooser and try
printing again.
The print job is paused.
(The printer is in Sleep
mode.)
2.
1.
In Mac OS X, restart the print job as follows.
2.
1.
In Mac OS 9, restart the print job as follows.
Open imagePROGRAF Printmonitor.
Choose Resume Printing in the File menu to restart
the print job.
2.
1.
The Printer Does
Not Respond Even if
Print Jobs are Sent
Phenomenon Cause Corrective Action
Wait until the system has been lled with ink. This
process may take about ten minutes.
When the printer
was turned off
previously, some
cleaning operation was
terminated.
The Display Screen
indicates the system
is lling with ink
The printer is not
selected in the printer
driver. (The printer is in
Sleep mode.)
In Windows, select the printer by clicking Select Printer
or Printer in the printing dialog box and try printing
again.
The printer is ofine.
Select the printer icon in the Printers and Faxes (or
Printers ) window.
Clear Pause Printing in the File menu to restart the
print job.
In Windows, restart the print job as follows.
Open the Printer Setup Utility (or the Print Center ).
Select the printer, and then Start Jobs in the Printers
menu to restart the print job.
Press the Online button on the Control Panel to bring
the printer online.

Canon imagePROGRAF iPF710 Specifications

Printer Specifications

print resolution (max.)	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm
number of nozzles	Matte Black: 5, 120 Nozzles, Other Colors: 2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print head swath	1.07 inch

Ink Specifications

ink type	Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K); Pigment: Matte Black (MBK) – Two Channels
ink tank capacity	130ml per Color
number of colors	5

Media Specifications

media width (roll feed)	10" – 36" (254mm – 914.4mm)
media width (cut sheet)	8" – 36" (203.2mm – 914.4mm)
printable margins (roll feed)	All Sides: 0.12" (3mm) or 0" for Borderless
minimum printable media length (roll feed)	8.0" (203mm)
maximum print length (roll feed)	59' (18m)
maximum print length (cut sheet)	5.2' (1.6m)
borderless printing widths (roll media only)	10", 14", 16", 24", 36", B2 (20.28"/515mm), A1 (23.38"/594mm), B1 (28.66"/728mm), AO (33.11"/841mm)
media thickness (roll feed)	0.07 – 0.8mm (2.8 – 31.4mil)
media thickness (cut sheet)	0.07 – 0.8mm (2.8 – 31.4mil)
media core sizes	2" or 3" Core (2/3" Core Adapter Included)
maximum roll outer diameter	5.9" (150mm)

Power and Acoustic

power supply	AC 100–240V (50-60Hz)
power consumption (maximum)	140W or Less
power consumption (standby)	5W or Less (10W or less when IEEE1394 is mounted)
power consumption (power off)	1W or Less (Executive Order Compliant)
acoustic noise (operation)	52dB (A) or Less
acoustic noise (standby)	35dB (A) or Less
acoustic power	6.6 Bels or Less

Operating Environment

operational temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (h x w x d)	59.3" x 34.3" x 43.1" / 1507mm x 871mm x 1094mm
weight (with stand)	Approx. 141 lb. / 64kg
