Canon imagePROGRAF iPF710 User Manual

Responding to Messages
59
Error Messages
Cause
Corrective Action
The Maintenance Cartridge is
full.
After conrming that the printer
has stopped operating, replace the
Maintenance Cartridge.
Maintenance cartridge full.
The Maintenance Cartridge is
not installed.
Install the Maintenance Cartridge.No maintenance cartridge.
(→"Replacing the Maintenance
Cartridge," User Manual)
(→"Replacing the Maintenance
Cartridge," User Manual)
The Maintenance Cartridge is
almost full.
You can continue to print, but
prepare a new Maintenance
Cartridge to use when the message
for replacement is displayed.
Prepare for maint cart
replacement.
Rel lever is in wrong
position.
The Release Lever is pushed
back.
Pull the Release Lever forward.
Top cover is open. The printer has detected that
the Top Cover is open.
Open the Top Cover fully, remove
any foreign objects, and close the
Top Cover again.
If the error occurs again, turn off
the printer and wait a while before
restoring power.
No Maintenance Cartridge
capacity.
The Maintenance Cartridge
cannot absorb enough ink for
Printhead cleaning or other
operation.
After conrming that the printer
has stopped operating, replace the
Maintenance Cartridge.
(→"Replacing the Maintenance
Cartridge," User Manual)
ERROR Exxx-xxxx (x
represents a letter or number)
An error may have occurred
that requires service.
Turn off the printer and wait at least
three seconds before restoring
power.
If the message is displayed again,
write down the error code and
message, turn off the printer, and
contact your Canon dealer for
assistance.
Hardware error.
xxxxxxxx-xxxx (x represents
a letter or number)
The last portion of roll paper
was used during a print job, and
paper could not be advanced
because the trailing edge is
taped to the roll.
Turn off the printer and remove the
roll before restoring power.
Fastening tape or the Belt
Stopper has not been removed
inside the Top Cover.
Turn off the printer, open the Top
Cover, and remove the tape or Belt
Stopper before restoring power.
An error may have occurred
that requires service.
Write down the error code and
message, turn off the printer, and
contact your Canon dealer for
assistance.

Canon imagePROGRAF iPF710 Specifications

Printer Specifications

print resolution (max.)	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm
number of nozzles	Matte Black: 5, 120 Nozzles, Other Colors: 2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print head swath	1.07 inch

Ink Specifications

ink type	Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K); Pigment: Matte Black (MBK) – Two Channels
ink tank capacity	130ml per Color
number of colors	5

Media Specifications

media width (roll feed)	10" – 36" (254mm – 914.4mm)
media width (cut sheet)	8" – 36" (203.2mm – 914.4mm)
printable margins (roll feed)	All Sides: 0.12" (3mm) or 0" for Borderless
minimum printable media length (roll feed)	8.0" (203mm)
maximum print length (roll feed)	59' (18m)
maximum print length (cut sheet)	5.2' (1.6m)
borderless printing widths (roll media only)	10", 14", 16", 24", 36", B2 (20.28"/515mm), A1 (23.38"/594mm), B1 (28.66"/728mm), AO (33.11"/841mm)
media thickness (roll feed)	0.07 – 0.8mm (2.8 – 31.4mil)
media thickness (cut sheet)	0.07 – 0.8mm (2.8 – 31.4mil)
media core sizes	2" or 3" Core (2/3" Core Adapter Included)
maximum roll outer diameter	5.9" (150mm)

Power and Acoustic

power supply	AC 100–240V (50-60Hz)
power consumption (maximum)	140W or Less
power consumption (standby)	5W or Less (10W or less when IEEE1394 is mounted)
power consumption (power off)	1W or Less (Executive Order Compliant)
acoustic noise (operation)	52dB (A) or Less
acoustic noise (standby)	35dB (A) or Less
acoustic power	6.6 Bels or Less

Operating Environment

operational temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (h x w x d)	59.3" x 34.3" x 43.1" / 1507mm x 871mm x 1094mm
weight (with stand)	Approx. 141 lb. / 64kg
