Canon imagePROGRAF iPF710 User Manual

Replacing Ink Tanks
10
Press the OK button and insert the Ink T
ank into the holder facing as shown in the
figure,withtheinkholesdown.
Important
•
Ink Tank cannot be loaded in the holder if the color or orientation is wrong.
If the Ink Tank do es not fit in t he holder, do not
force it i nto the holder. Make sure
the color of the InkTankLockLevermatches the color of the Ink Tank,and
check the orientation of the Ink Tank before reloadin g it.
11
Close the InkTankLockLeveruntil it clicks.
36

Canon imagePROGRAF iPF710 Specifications

Printer Specifications

print resolution (max.)	2400 x 1200 dpi
line accuracy	±0.1% or Less
minimum line weight	0.02mm
number of nozzles	Matte Black: 5, 120 Nozzles, Other Colors: 2, 560 Nozzles per Color
droplet size	4 Picoliter
nozzle pitch (head resolution)	1200 dpi x Two Rows
print head swath	1.07 inch

Ink Specifications

ink type	Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K); Pigment: Matte Black (MBK) – Two Channels
ink tank capacity	130ml per Color
number of colors	5

Media Specifications

media width (roll feed)	10" – 36" (254mm – 914.4mm)
media width (cut sheet)	8" – 36" (203.2mm – 914.4mm)
printable margins (roll feed)	All Sides: 0.12" (3mm) or 0" for Borderless
minimum printable media length (roll feed)	8.0" (203mm)
maximum print length (roll feed)	59' (18m)
maximum print length (cut sheet)	5.2' (1.6m)
borderless printing widths (roll media only)	10", 14", 16", 24", 36", B2 (20.28"/515mm), A1 (23.38"/594mm), B1 (28.66"/728mm), AO (33.11"/841mm)
media thickness (roll feed)	0.07 – 0.8mm (2.8 – 31.4mil)
media thickness (cut sheet)	0.07 – 0.8mm (2.8 – 31.4mil)
media core sizes	2" or 3" Core (2/3" Core Adapter Included)
maximum roll outer diameter	5.9" (150mm)

Power and Acoustic

power supply	AC 100–240V (50-60Hz)
power consumption (maximum)	140W or Less
power consumption (standby)	5W or Less (10W or less when IEEE1394 is mounted)
power consumption (power off)	1W or Less (Executive Order Compliant)
acoustic noise (operation)	52dB (A) or Less
acoustic noise (standby)	35dB (A) or Less
acoustic power	6.6 Bels or Less

Operating Environment

operational temperature	59 – 86 F° (15 – 30 C°)
relative humidity	10 – 80% (No Condensation)

Weight and Dimensions

printer dimensions (h x w x d)	59.3" x 34.3" x 43.1" / 1507mm x 871mm x 1094mm
weight (with stand)	Approx. 141 lb. / 64kg
