WebCAM user manual -5-
Chapter 3: WebCAM, USB Camera and the Network
Chapter 3: WebCAM, USB Camera and the Network
The following details the installation procedure for WebCAM.
Section 1. Installation Procedure
Step 1:
Connect the PC camera
into the USB port of
WebCAM.
Step 2:
Connect the WebCAM to
LAN by using the
Ethernet UTP port.
Step 3:
Connect DC power
adapter output into
WebCAM socket, and
plug the DC power input
into the wall socket
