WebCAM user manual -84-
Appendix A: Router Configuration
SMC (http://www.smc.com)
SMC2404WBR – Barricada Turbo 11/22 Mbps Wireless Cable/DSL Broadband
Router
SMC7004VBR – Barricada Cable/DSL Broadband Router
SMC7004CWBR – Barricada Wireless Cable/DSL Broadband Router
1. Log into your router using your router IP.
2. After you are logged in, click NAT on the left side of the page.
3. Click on Virtual Server on the left side of the page.
4. Enter the following information on the page:
Line #1:
Private IP: Type in the camera’s IP address, for example:
192.168.0.5 (Look at WebCAM’s IP Address LCD
display for the last 3 digits of the camera’s IP address)
Private Port: 80
Type: TCP
Public Port: 80
Line #2
Private IP: Type in the camera’s IP address, for example:
192.168.0.5 (Look at WebCAM’s IP Address LCD
display for the last 3 digits of the camera’s IP address)
Private Port: 9001
Type: UDP
Public Port: 9001
5. Click Apply to save the settings. WebCAM should now be configured to work with
your router and be accessible from the Internet.
SMC7004AWBR – Barricade 4-port 11Mbps Wireless Broadband Router
1. Log into your router using your router IP.
2. Click on Virtual Server on the left side of the page.
3. Enter the following information on the page:
For ID #1:
Service Port: 80
Private IP: Type in the camera’s IP address, for example:
192.168.0.5 (Look at WebCAM’s IP Address LCD
display for the last 3 digits of the camera’s IP address)
Enable: Checked in
