Canon iR2200 User Manual

COPYRIGHT © 2001 CANON INC. 2000 2000 2000 2000 CANON iR2200/iR2800/iR3300 REV.0 MAR. 2001
CONTENTS
T1
Contents
CHAPTER 1 MAINTENANCE AND INSPECTION
CHAPTER 2
IMAGE ADJUSTMENT BASIC PROCEDURE
1 Periodically Replaced Parts........... 1-1T
1.1 Reader Unit ............................. 1-1T
1.2 Printer Unit ............................. 1-1T
1.3 Side Paper Deck...................... 1-1T
1.4 Cassette Feeding unit .............. 1-1T
1.5 Inner 2-Way Tray .................... 1-1T
2 Consumables and Durables ........... 1-2T
2.1 Checking the Time of
Replacement .............................1-2T
2.2 Reader Unit ..............................1-2T
2.3 Printer Unit ...............................1-2T
2.4 Side Paper Deck .......................1-3T
2.5 Cassette Feeding Unit ...............1-3T
2.6 Inner 2-Way Tray-A1 ...............1-3T
3 Periodical Servicing Procedure .......1-4T
4 Scheduled Servicing Chart ..............1-6T
4.1 Reader Unit ..............................1-6T
4.2 Printer Unit ...............................1-7T
5 Points to Note for Scheduled
Servicing .........................................1-8T
6 Cleaning the Bottom of the
Developing Assembly .....................1-9T
6.1 Cleaning the Bottom of the
Developing Assembly ..............1-9T
1 Making lnitial Checks ................... 2-1T
2 Checking the Scanner Side ........... 2-1T
3 Checking the Printer Side (1/3)..... 2-2T
4 Checking the Printer Side (2/3)..... 2-2T
5 Checking the Printer Side (3/3)..... 2-2T
CHAPTER 3 STANDARDS AND ADJUSTMENTS
1 Image Adjustments ........................ 3-1T
1.1 Standards of Image Position ... 3-1T
1.2 Checking the Image Position .. 3-2T
1.3 Adjusting Left/Right
lamge Margin ...........................3-3T
1.3.1 Adjusting the Registration
for the Cassette Rear Front .3-3T
1.3.2 Adjusting the Registration
for the Multifeeder
Rear Front ..........................3-4T
1.3.3 Adjusting the Registration
for the Deck .......................3-4T
1.3.4 Duplex Feeding Unit ..........3-5T
1.4 Adjusting the Image Leading
Edge Margin .............................3-5T
1.5 Adjusting the Left/Right
Non-Image Width .....................3-5T
1.6 Adjusting the Leading Edge
Non-Image Width .....................3-6T
2 Scanning System ............................3-6T
2.1 After Replacing the Scanning
Lamp ........................................3-6T
2.2 Mounting the Motor Unit .........3-7T
2.3 Routing the Scanner
Drive Cable ..............................3-8T
2.4 Adjusting the Position of the
No. 1/No. 2 Mirror Base ..........3-9T
2.5 Mounting the Copyboard
Glass ......................................3-11T
2.6 Mounting the Reader Upper
Frame .....................................3-12T

Canon iR2200 Specifications

General

Print Technology	Laser
Print Speed	22 ppm
Max Paper Size	A3
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Network Connectivity	Optional
Copy Speed	22 cpm
Scanner Type	Flatbed
Max Print Resolution	600 x 600 dpi
Zoom Range	25% - 400%
