CHAPTER 5 SERVICE MODE
5-35 T
3.5 SORTER
Indicates the input/output ports for the finisher controller PCB.
<SORTER (1/8)>
3.5.1 Finisher-J1
Address bit Notation Description Remarks
IO-P001 0 not used
(input) 1 not used
2 S10 stack tray paper height sensor signal 1: upper limit
3 S1 fisher front cover sensor signal 1: closed
4 S11 stack tray paper sensor signal 1: paper present
5 S12 stack tray lower limit sensor signal 1: lower limit
6 S13 stack tray upper limit sensor signal 1: upper limit
7 S3 return roller home position sensor signal 1: HP
IO-P002 0 S11 stack tray paper sensor signal 1: HP
(input) 1 IPC chip select 1: selected
2 S2 input sensor signal 1: paper present
3 S4 stack retaining lever home position sensor signal 0: HP
4-7 not used
IO-P003 0 S7 rear alignment home position sensor signal 1: HP
(input) 1 S6 front alignment home position sensor signal 1: HP
2 S8 stack delivery lever home position sensor signal 0: HP
3 S5 intermediate handling tray paper sensor signal 1: paper present
4 S14 staple cartridge sensor signal 0: detected
5 S15 staple absent sensor 0: detected
6 S16 stapling home position sensor signal 0: detected
7 S17 stapler edging sensor signal 0: detected
IO-P004 0 delivery motor clock sensor signal -
(input) 1 S9 stack tray up/down clock sensor signal -
2-7 not used
IO-P005 0 M5 stack tray ascent/decent motor CW signal 1: up ON
(output) 1 not used
2 M5 stack try ascent/descent motor CCW signal 1: down ON
3-4 not used
5 M1 delivery motor current switch 2 (T05-301-01)
6-7 not used
COPIER>I/O>SORTER
