Canon LBP7660Cdn - Clearing Paper Jams (Back Cover)

To Next Page

To Previous Page

0258-0C6

Referring to the procedure on the display, follow the steps below to remove jammed documents.

Press [ ].

Open the back cover.

Open the paper output guide by holding the green tab (A).

Remove the paper by pulling it gently.

Clearing Paper Jams (Back Cover)
