Canon MultiPASS MP360 - Page 59

Chapter 3
3-8
F-3-4
Reference
The right front cover has 7 claws, and remaining claws will unhook by themselvs after detaching outer claws in step
3 and 4. Please refer to the below image for the position of claws (view of the reverse side).
F-3-5
(5) Insert a precision flat bladed screwdriver in an upright posture in a narrow gap between the left front cover and
d
Right Fromt Cover
