Canton Sound M User Manual

28
English
To change the Input Select function from Manual to Auto or contrary, proceed as follows:
1
To enter the menu, press the "M" button.
2
Use the " " or " " button to navigate into the menu System Setup [SYS] and confirm with the "OK" button�
3
Use the " " or " " button to select the menu item Input Select [SEL] and confirm with the "OK" button�
4
Change the setting using the "+" or "–" button and confirm with the "OK" button�
5
Press the "M" button to exit this menu item�
Notes: • If you want the HDMI® inputs to be switched automatically too, please activate the CEC function�
• To automatically switch from the optical or coaxial digital input to one of the other inputs, the source unit must be switched off�
For analog Line and Bluetooth® stopping playback is sufficient�
Sub Output [OUT]
The Sound M has a build-in subwoofer� Therefore the function Sub Output [OUT] is deactivated ([OFF]) by default� To expand the frequency range
and to enhance low level frequency reproduction the Sound M can be extended with an external subwoofer� You can integrate an additional sub-
woofer in the following ways:
• Connecting an active subwoofer using a RCA cable: If you set the function "Sub Out" to wired [WRD], you can connect your active subwoofer to the
SUB OUT on the rear of the Sound M using a cinch-RCA-cable� In this case the internal subwoofer of the Soundbar will automatically be limitied
to 80Hz and frequencies below 80Hz will be routed to the external subwoofer�
• Pairing a wireless subwoofer from Canton Smart-series: The Sound M has a build-in wireless transmitter that can stream audio and control commands
wirelessly from the Soundbar to paired wireless speakers and/or subwoofers from the Canton Smart-series within your room�
In case you have paired a wireless subwoofer in the menu "Wireless Setup [WIS] / Speaker Pairing [WSP]", the option "Wireless [WLS]" will additionaly be
available in the "Sub Output" menu� This means, that the connected subwofer gets the audio as well as the control commands (state, volume, etc�) wirelessly�
• Connecting a wireless subwoofer from the Canton Smart-series using a signal cable: As an alternative to the wireless audio transmission, you can connect
your subwoofer with a signal cable, so that the audio data is transmitted over the RCA cable and the control commands are transmitted wirelessly�
This way, the Smart subwoofer can be used like a "normal" subwoofer, but will still be controlled and adjusted by the Sound M� To do so, please set
the option to "Wireless [WLS]" after you have successfully paired a Smart subwoofer according to chapter "Wireless Speaker Pairing [WSP]"�
To enable resp� disable the subwoofer output, please do the following:
1
To enter the menu, press the "M" button.
2
Use the " " or " " button to navigate into the menu System Setup [SYS] and confirm with the "OK" button�
3
Use the " " or " " button to select the menu item Sub Out and confirm with the "OK" button�
4
Change the setting Wired [WRD] or Off[OFF], in case Wireless [WLS] using the "+" or "–" button and confirm your selection with the "OK" button�
5
To leave the menu, press the "M" button�

Canton Sound M Specifications

General

Audio decoders	DTS Digital Surround, Dolby Digital
RMS rated power	300 W
Audio output channels	2.1 channels
Audio Return Channel (ARC)	Yes
Wi-Fi	-
HDMI in	3
Bluetooth version	5.0
HDMI ports quantity	4
Number of HDMI outputs	1
Connectivity technology	Wired & Wireless
Woofer diameter	50 mm
Tweeter diameter	19 mm
Crossover frequency	3000 Hz
Woofer diameter (imperial)	2 \
Tweeter diameter (imperial)	0.75 \
Cables included	AC, HDMI, Optical
Display type	LED
Product color	Black
Power consumption (standby)	0.4 W

Weight and Dimensions

Depth	100 mm
Width	725 mm
Height	65 mm
Soundbar weight	4000 g
