Accelerator Lever
. . . . . . . . . . This increases or decreases the engine speed.
Steering Lever
. . . . . . . . . . . . This is used when turning the machine and when
ch ang ing t he direc tion or trave l (FO RWAR D or
REVERSE).
Dump Lever
. . . . . . . . . . . . . . . This is used to raise or lower the dump body.
Lock Plate
. . . . . . . . . . . . . . . . This is used to lock the dump lever.
H/L Speed Selecter Switch
. . .
This is used to switch the travel speed between [HI] and
[LO].
Parking Brake Switch
. . . . . . .
This is used when parking the machine. (When the
parking brake switch is at the [P] position, the machine
does not move even when the steering lever is operated.)
Lamp Switch
. . . . . . . . . . . . . . Pressing this button lights up the head lamps.
Horn Button
. . . . . . . . . . . . . . . Pressing this switch sounds the horn.
Turn Lever
. . . . . . . . . . . . . . . . This lever is used when turning the load deck body (turn
and dump model).
Dump Lever
. . . . . . . . . . . . . . . This lever is used when dumping the load deck body.
Ignition Switch
. . . . . . . . . . . . . This also acts as the main switch. When the key is turned
to the [ ] position, electric current passes through the
electrical circuits of the machine. If the key is turned
further to the [ ] position, the starting motor is cranked. If
the key is turned to the [ ] position, electricity flows to the
glow lamp.
Coolant Temperature Lamp
. . This lights up when the engine cooling water temperature
rises abnormally (overheats).
