Controls and Components
-16-
2
Oil Pressure Lamp
. . . . . . . . . . This shows if the engine oil pressure is normal. When the
engine starting switch is turned to the [ ] position,it lights
up, and if the conditions are normal it will go out after the
engine starts.
Parking Brake Lamp
. . . . . . . . This lights up when the parking brake switch is at the [P
(parking)] position.
Charge Lamp
. . . . . . . . . . . . . . This displays the condition of the battery charge. When
the engine starting switch is turned to the [ ] position, it
lights up, and if the condition is normal, it will go out after
the engine starts.
Fuel Gauge
. . . . . . . . . . . . . . . .
This shows the remaining amount of fuel.
Hour Meter
. . . . . . . . . . . . . . . .
This displays the total number of hours that the machine
has been working in units of 0.1 hour.
