69
IR32 W & Z vers. NTC: Collegamenti / Connections
c
1
2
3
654789
DIG.INPOWER NTC1 NTC2
COM
OUT 1
SERIAL
LINK
12÷24 V
2 VA
OUT 2
13 14 15
c
OUT 3
10 11 12
c
OUT 4
16 17 18
c
c
1
2
3
654789
DIG.INPOWER NTC1 NTC2
COM
OUT 1
SERIAL
LINK
12÷24 V
2 VA
OUT 2
13 14 15
c
Versione W, alimentazione
12÷24 Vac/Vdc, ingresso
NTC
Version W, power supply
12÷24Vac/Vdc, NTC input
Versione Z, alimentazione
12÷24Va/Vdc e ingresso
NTC
Version Z, power supply
12÷24 Vac/Vdc, NTC input
