Carel universal infrared series User Manual

77
Connessione sonde Carel / Carel probe connections
789
123
IR32
IRDR
ponticello / bridge
Pt100E
cavi dello stesso colore
wires with the same color
Pt100A1/A2
rosso / red blu/ blue
TcJ
rosso / red verde/ green
TcK
bianco / white
marrone/ brown
out T
or
out H
M+
SpK
Sonde attive
Active probe
+05-3015 • rel.3.0 interno ok 18-09-2002 14:31 Pagina 77
