Value of the main parameters with the different Function Modes.
Each Function Mode has a defined set of values for Set-points and main parameters.This
means that, when the Function Mode is modified, the instrument will automatically store the
set of values associated to the selected Mode.
The table below shows the values associated with the first 9 Modes. Mode 2 has been
highlighted because it is the f
actory-set one (Default value).In any moment it is possible to
reset the Default value using the ‘Reset procedure’(see pag. 57).
49
Advanced set-up: Parameters default values
Par. Descript. Mode 1 Mode 2 Mode 3 Mode 4 Mode 5 Mode 6 Mode 7 Mode 8 Mode 9
St1 Set-point 1 20 20 20 20 20 20 20 20 20
St2 Set-point 2 absent absent absent absent absent 40 40 40 40
P1 Hysteresis 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0 2.0
P2 Hysteresis absent absent 2.0 2.0 2.0 2.0 2.0 2.0 2.0
P3 Dead-Band absent absent 2.0 2.0 2.0 absent absent absent absent
P14 Probe Calibr. 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
P25 Lower al.(1) -100 -100 -100 -100 -100 -100 -100 -100 -100
P26 Higher al. (2) 999 999 999 999 999 999 999 999 999
P27 Alarm Hyster. 2 22222222
P28 Alarm del. (3) 60 60 60 60 60 60 60 60 60
(1): -50 NTC input
(2): 90 for NTC input, +600 for Pt100 input.
(3): minutes
