The Universal Infrared instruments are capable of performing a lot of extra functions
besides those described in the Advanced Programming Procedure section, thanks to some
special parameters (Cxx type).
For your convenience the table below lists all the standard parameters of the Infrared
regulators (Pxx and Cxx types) except those regarding the Special Mode. Each
parameter will be accompanied by just a brief description because we assume you already
know the meaning and function mode of each single parameter.We strongly recommend
reading carefully the Technical Manual of the Universal Infrared Range before using the
special parameters.
To access the full parameter list, follow the procedure indicated on page 49 but replace the
password “22” with “77”. If you enter the right password, the display will show the first
parameter of the list, that is C0.To display and modify the value of the parameter follow the
procedure described above. Similarly, in order to confirm any modification, press “6”.
Par. Description Min. Max Default
St1 Set Point 1 min. probe max. probe 20
St2 Set Point 2 (Function Modes 6, 7, 8, 9) min. probe max.probe 40
C0 Function Mode (see page 42) 1 9 2
Setting the Hysteresis (see pages 37 and 42)
P1 Hysteresis of Set Point 1 0.1 99.9 2.0
P2 Hysteresis of SP 2 (F. Modes 3,4,5,7,8,9) 0.1 99.9 2.0
P3 Dead-Band (Function Modes 3,4,5) 0 99.9 2.0
52
Advanced set-up: list of parameters
