Carimali Optima Silver - Testing Actuators Group 2; Testing Actuators Group 3; Milk Pump Testing

lb-05046-03-EN Pag.47 22/01/2014
Test actuators
- Actuators 1
- Actuators 3
- Milk pump
- Mixer A
- Dispenser A
- Exhaust fan
- Electronic fan
Actuators 2
Actuators 2
Enter
PRESS A DOSE KEYS BETWEEN T1
TO T6 TO ACTIVATE THE ACTUATOR
THAT YOU WISH TO CHECK.
PRESS THE SAME DOSE KEY TO
STOP THE ACTIVATED ACTUATOR
FROM WORKING.
WARNING : press INFO key to
display the actuators legend
and relevant connectors on
master board.
Esc
Test Actuators
T 1 Coffee heater xx c°
T 2 Anti flooding solenoid valve
T 3 Mixer A solenoid valve
T 5 Group heater
T 7
Hot water s.v. ( not available )
Test actuators
- Actuators 1
- Actuators 2
- Milk pump
- Mixer A
- Dispenser A
- Exhaust fan
- Electronic fan
Actuators 3
Actuators 3
Enter
PRESS A DOSE KEYS BETWEEN T1
TO T6 TO ACTIVATE THE ACTUATOR
THAT YOU WISH TO CHECK.
PRESS THE SAME DOSE KEY TO
STOP THE ACTIVATED ACTUATOR
FROM WORKING.
WARNING : press INFO key to
display the actuators legend
and relevant connectors on
master board.
Esc
Test Actuators
T 1 Steam heater xx c°
T 2 Steam Milker solenoid valve
T 3 Air milker solenoid valve
T 4 Rinse Milker solenoid valve
T 5 Fill -up solenoid valve
T 6 Steam nozzle sol. Valve
T 7 Power cleaner sol. valve
Test actuators
- Actuators 1
- Actuators 2
- Actuators 3
- Mixer A
- Dispenser A
- Exhaust fan
- Electronic fan
Milk pump
Milk pump
Enter
Esc
Test actuators
Milk pump speed
0 %
CHARGE
T1 Change direction
Keep pressed the + key to increase the
speed of the Milk pump. Keep pressed
the – Key to decrase the speed.
Press the n° T 1 key to change the spin
direction of the Milk pump.
+
-
+
-
+
-
