Carlson RT4 User Manual
LED acvity indicators are located on the front of the RT4 in the upper-le
corner.
• Red LED, solid: 1) When the RT4 is put to sleep or powered o by
pressing the power key , the red LED is solid unl the unit has
successfully completed the process, and then the red LED turns o. If
powering o the device, do not remove the baery while the light is
solid. 2) The AC wall charger is plugged in and the baery is full (not
charging).
• Red LED, blinking: The AC wall charger is plugged in and the baery is
in the process of charging.
• Green LED, solid: Turns on when the system is boong,
programmable.
• Blue LED, solid or blinking: Programmable.
• Amber Light: Front or rear facing camera is in use.
The green and blue LEDs are in the same locaon. They cannot be shown
simultaneously. These LEDs can be programmed by a developer. Sample
code is available upon request.
All units have an ambient light sensor located on the front of the RT4 in the
upper-right corner. The light sensor dynamically adjusts the backlight on
the display.
You can disable this process and manually control the display brightness
if you prefer. Go to the Start menu and select Sengs > System > Display.
Turn o Change brightness automacally when lighng changes and tap
Apply. To manually adjust the display backlight, tap on the baery icon
at the boom of the desktop screen. The display backlight brightness
can easily be toggled up or down in 25% increments from 0% to 100% by
tapping the percent le (see the sun icon).
LED Acvity
Indicators
Light Sensor
LED Indicators
