• Do not touch the docking pins (spring loaded contacts) with
conducve items when power is applied to the dock.
• Do not drop items on the dock that can damage the pins.
• Keep debris o of the docking pins.
Vehicle Dock
The Vehicle Dock is part of a mounng system that provides the RT4 with a
method to be secured in a vehicle or other mobile mounng applicaon.
Note: There is a powered version and a non-powered version.
Vehicle Dock Features:
• A locking mechanism with a unique key (duplicates can be made for
eets)
• Powered dock: 12 VDC power port, vehicle charger, and USB 2.0 port
(host)
• Four holes and screws for aachment to a mounng system (details
follow)
Mounng System
The Vehicle Dock does not aach directly to a vehicle. The dock aaches
to any 30mm x 38mm AMPS mounng system that suits your applicaon
(sold separately). We recommend products from RAM Mounts (rammount.
com) or ProClip (proclipusa.com).
