Carlson Rugged Tablet RT4 - Office Docking Station

38 | Page
Carlson RT4 User Manual
Congure pin 9 as input or power supply: Pin 9 is the Ring-In signal
input. It is rarely used by devices anymore and has become a popular
pin to provide a power source to an RS-232 device.
Select Input if your device uses Ring-In signal or if it does not need to
be powered from the RS-232 port.
Select Power supply enabled to make pin 9 a power supply to be used
by the RS-232 device. The power supply is enabled automacally
without needing any interacon with the COM port. Depending on the
model, the power supply supplies either 5 VDC or 12 VDC.
• Select DTR enables power supply to make pin 9 a power supply (5 VDC
or 12 VDC depending on model). The power supply remains o unl
the user applicaon opens the COM port and asserts the DTR signal.
When the DTR signal de-asserts, the power supply turns o again.
• Check Disable power supply during sleep to cause the power supply to
automacally turn o when the tablet is in sleep mode. This can allow
the RS-232 device to conserve baery power in sleep mode. If your
app and/or RS-232 device experiences communicaon failures when
the RT4 enters or exits sleep mode, then leave this opon unchecked.
Oce Docking Staon
The Oce Docking Staon enables you to perform the following funcons:
• Charge your RT4 Rugged Tablet
• Use your RT4 as a desktop computer
• Transfer data to or from another computer or network via the
Ethernet connecon
Oce Docking
Staon
