Applications and Machine Specifications
Applications
With its sleek design, the Model 860 neatly coils long lengths of flexible wire, cable, and tubing.
This unit’s unique coiling bowl and adjustable tube assembly can coil material to a specific
finished coil diameter, utilizing interchangeable coiling bowl inserts. When interfaced with
applicable Carpenter Mfg. Co., Inc. Measure & Cut or Measure, Cut & Strip equipment the
Model 860 will automatically start and stop, allowing for seamless operation. The Model 860
utilizes an easy-to-use electronic control that manages all coiling bowl functions. This unit may
also be operated manually with an optional foot switch assembly for use in conjunction with
competitive material processing machines. This unit is a great solution for controlling material
output in neat, efficient fashion.
Machine Specifications*
Maximum Material Diameter
0.375” (9.5 mm)
Minimum Material Length
72.0” (1,829 mm) [dependent on finished coil diameter]
Minimum Finished Coil Diameter
Less than 12.0” (304 mm) [application dependent]
Maximum Finished Coil Diameter
12.0” (304.8 mm)
Maximum Coiling Speed
175 RPM
Input Height
35.25” (895.3 mm) to 44.25” (1,123.9 mm)
Electrical Connection (Standard)
115 VAC, 60 Hz, 2 AMP
Electrical Connection (Optional)
230 VAC, 50 Hz, 1 AMP
Dimensions
16.5” (419.1 mm) x 35.25” (895.3 mm) to 44.25” (1,123.9 mm)
x 16.0” (406.4 mm) [W x H x D]
Weight
52 Pounds (23.6 Kilograms)
Warranty
1-year Limited Warranty
*Machine specifications subject to change without notice.
