PN 9599 Foot Switch Assembly (Model 360, Model 930, or Model 970)
For Model 360: The interface between the Model 360 and the Model 860 may be controlled by a
PN 9599 foot switch assembly. To install the foot switch assembly, insert the 15-pin “D”
connector at the end of the foot switch assembly cable into the PN 9686 accessory board kit
previously installed on the back of the Model 360.
After installing the foot switch assembly, press the MENU button on the Model 360 to toggle
through the options and press ENTER when “FOOTSWITCH ON/OFF” is shown. Press
CLEAR to toggle between “FOOTSWITCH ON” and “FOOTSWITCH OFF” and press
ENTER.
1. When processing material with a foot switch assembly, the Model 860 “RESTART
DWELL” should be set to 0.
2. Press the RUN button on the Model 360. The display will read the following: “PRESS
FOOTSWITCH OR PRESS STOP.” Press and release the foot switch assembly to begin
processing material.
3. The Model 360 will display the same message above after completion of each piece of
material. Simply press and release the foot switch assembly to continue, or press the
STOP button to quit.
For Model 930 or Model 970: The interface between the Model 930 or Model 970 and the
Model 860 may be controlled by a PN 9599 foot switch assembly. To install the foot switch
assembly, insert the 15-pin “D” connector at the end of the foot switch assembly cable into the
PN 9686 accessory board kit previously installed on the back of the Model 930 or Model 970.
After installing the foot switch assembly, press the FOOT SWITCH button on the Model 930 or
Model 970 to activate this option.
1. When processing material with a foot switch assembly, the Model 860 “RESTART
DWELL” should be set to 0.
2. Press the RUN button on the Model 930 or Model 970. The display will read the
following: “Press and release the foot switch to run the next piece. Or press STOP to
quit.” Press and release the foot switch assembly to begin processing material.
3. The Model 930 or Model 970 will display the same message above after completion of
each piece of material. Simply press and release the foot switch assembly to continue, or
press the STOP button to quit.
