Figure 2.6 Control Box Standard
Control Panel
Control Box (Front View with Cover Removed)
Intake Heater Switch
Ignition Switch
Total Time Meter
Water Temp Gauge Oil Pressure Gauge
Ammeter
I n t a k e He a t e r
Timer (IHT)
Starter S olenoid
Relay (SSR)
Circuit Breaker (CB4)
Circuit Breaker (CB3)
Circuit Breaker (CB2)
S t a r t e r S o le n o i d
Timer (SST)
Gr o u n d S t r a p
Assembly
Safety Relay
Intake Heater Relay
