Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
137 OF 168
137
INPUTS - Inputs Status
Name
Range
Default
Unit
Displayed text*
1
STAR_AUX
OPEN_CLOSE
OPEN
-
Compressor Start Contact
2
RUN_AUX
OPEN_CLOSE
OPEN
-
Compressor Run Contact
3
DMP_FC
NO_YES
NO
-
ECO DMP VLV Full Close
4
DMP_FO
NO_YES
NO
-
ECO DMP VLV Full Open
5
DMP_ACT
-
0
-
ECO DMP VLV Status
6
blank
-
-
-
Cl=0,Inter=1,Op=2,Fail=3
7
HGBP_FC
NO_YES
NO
-
EC/HG VLV Fully Close
8
HGBP_FO
NO_YES
NO
-
EC/HG VLV Fully Open
9
HGBP_ACT
-
0
-
EC/HG VLV Status
10
blank
-
-
-
Cl=0,Inter=1,Op=2,Fail=3
11
HP_SW
OPEN_CLOSE
OPEN
-
High Pressure Switch
12
REM_CON
OPEN_CLOSE
OPEN
-
Remote Start/Stop
13
E_STOP
OPEN_CLOSE
OPEN
-
Emergency Stop Contact
14
ICE_CON
OPEN_CLOSE
OPEN
-
Ice Build Contact
15
REM_LOCK
OPEN_CLOSE
OPEN
-
Chiller Lockout
16
SAFETY
OPEN_CLOSE
OPEN
-
Spare Safety Input
17
STARTFLT
OPEN_CLOSE
OPEN
-
Starter Fault Feedback
18
FS_LOCK
OPEN_CLOSE
OPEN
-
Fire Security Interlock
19
GV1_OHMS
-
0
-
Guide Vane 1 Actual Ohms
20
GV1_ACT
-
0
%
Guide Vane 1 Actual Pos
21
GV2_ACT
-
0
%
Guide Vane 2 Actual Pos
22
VFD_ACT
-
0
%
Actual VFD Speed Per
23
DIFF_ACT
-
0
%
Diffuser Actual Pos
