Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
138 OF 168
138
24
AUTO_DEM
-
0
mA
Auto Demand Limit Input
25
AUTO_RES
-
0
mA
Auto Water Temp Reset
26
REF_LEAK
-
0
mA
Refrig Leakage Sensor
27
VFD_IN
-
0
V
VFD Speed Feedback
28
GV1_MA
-
0
mA
GV1 Pos Feedback
29
GV2_MA
-
0
mA
GV2 Pos Feedback
30
VFDC_MA
-
0
mA
VFD Current Input
31
DMP_ACTP
-
0
%
ECO DMP VLV Actual Pos
32
DMP_MA
-
0
mA
ECO DMP VLV Current FB
33
HGBPACTP
-
0
%
EC/HG VLV Actual Pos Per
34
HGBP_MA
-
0
mA
EC/HG VLV Current FB
35
TRIPR
OPEN_CLOSE
OPEN
-
ISM Trip Relay Status
36
SHAFTDIS
OPEN_CLOSE
OPEN
-
Displacement Switch
37
POW_FDB
NO_YES
NO
-
Marine Pwr Req Feedback
38
FC_SS
OFF_ON
OFF
-
Free Cool Start Switch
39
CUS_ALE
OPEN_CLOSE
OPEN
-
Customer Alert
40
PGLE_LO
OPEN_CLOSE
OPEN
-
Purge Level Switch Low
41
PGLE_HI
OPEN_CLOSE
OPEN
-
Purge Level Switch High
42
HF_LS
OPEN_CLOSE
OPEN
-
Liquid Level Switch
*Depends on the selected language (English by default).
OUTPUTS - Outputs Status
Name
Range
Default
Unit
Displayed text*
1
GV1_OUT
-
0
mA
Guide Vane1 Output
2
GV1_DEC
OFF_ON
OFF
-
Guide Vane 1 Decrease
