Carrier SmartVu control User Manual

SRDC-UG-2-14-000
REVISION
DATE
PAGE
19 Series Carrier®
SmartVu
TM
–
Controls IOM
2.3
Dec 4, 2020
139 OF 168
139
3
GV1_INC
OFF_ON
OFF
-
Guide Vane 1 Increase
4
VFD_OUT
-
0
mA
VFD Speed Output mA
5
OIL_HEAT
OFF_ON
OFF
-
Oil Heater Relay
6
OIL_PUMP
OFF_ON
OFF
-
Oil Pump Relay
7
CHST_OUT
-
0
mA
Chiller Status (Analog)
8
RUN_STAT
OFF_ON
OFF
-
Chiller Status(Discrete)
9
ALM
OFF_ON
OFF
-
Alarm Relay
10
ALE
OFF_ON
OFF
-
Alert Relay
11
COMP_SR
OFF_ON
OFF
-
Compressor Start Relay
12
vfd_lock
OFF_ON
OFF
-
Danfoss VFD Interlock
13
TRANS
OFF_ON
OFF
-
Starter Trans Sw Status
14
EXV_OUT
-
0
mA
Oil Cooler EXV mA
15
exv_tgt
-
0
%
Oil Cooler EXV Target
16
dmp_tgt
-
0
-
ECO DMP VLV Tgt Pos
17
blank
-
-
-
Close=0, Hold=1, Open=2
18
DMP_OUT
-
0
mA
ECO DMP VLV Output mA
19
DMP_CL
OFF_ON
OFF
-
ECO DMP VLV Close
20
DMP_OP
OFF_ON
OFF
-
ECO DMP VLV Open
21
VS_SV
OFF_ON
OFF
-
Vapor Source SV
22
LQBP_TGT
-
0
%
ECO LBP VLV Target
23
LQBP_VLV
-
0
mA
ECO LBP VLV mA
24
hgbp_tgt
-
0
-
EC/HG VLV Target Pos
25
blank
-
-
-
Close=0, Hold=1, Open=2
26
HGBP_OUT
-
0
mA
EC/HG VLV Output mA
27
HGBP_OFF
OFF_ON
OFF
-
EC/HG VLV Close
28
HGBP_ON
OFF_ON
OFF
-
EC/HG VLV Open
